Scientists are presently working on creating a new type of concrete which will not only be able to reduce the carbon footprint of construction projects, but also serve as permanent storage for carbon dioxide within the structure. This solution does not only aim at reducing the emissions, but actually involves using concrete as a carbon sink in which carbon dioxide gets embedded.
Concrete has always been widely used, and yet cement production accounts for a large part of the world's carbon footprint. This is because the production of clinker, a key component of cement, is conducted under extremely high temperatures, leading to the emission of carbon dioxide. It has been found that cement production alone contributes to about 8% of the world's carbon footprint.
How the new concrete works?
The researchers who are working within the framework of the European C-SINC project have managed to create a material that acts as a binder, replacing some of the usual ingredients of cement with magnesium compounds. The reaction of this material with the CO2 leads to the formation of solid matter and the absorption of greenhouse gas. The process is environmentally friendly since it reduces the usage of regular clinker and utilizes harmful CO2.
The process;
- Uses magnesium-rich silicate minerals
- CO₂ is captured from industrial emissions
- Converted into magnesium carbonate (solid mineral)
- Carbon becomes permanently locked inside concrete
- Reduces dependence on traditional clinker
Instead of treating carbon dioxide as waste, the system uses it as a raw material for construction.
CO2 to Stone Conversion
The novel approach lies in a technique called accelerated mineralization, wherein the carbon dioxide is transformed through chemical reactions into stable carbonate minerals. This chemical reaction results in the binding together of CO2 along with the magnesium-containing minerals. When that is done, the CO2 is not present in any gaseous form anymore and becomes part of the concrete. It remains stable and cannot escape for an extensive period.
The process
- CO₂ reacts with magnesium compounds
- Forms stable carbonate minerals
- Carbon shifts from gas to solid form
- Becomes part of the hardened structure
Once this happens, the carbon is not expected to escape easily because it is chemically bound in a mineral form.
Structural tests in practice
The material is currently being tested structurally outside the lab environment in Karlsruhe, Germany, at the Karlsruhe Institute of Technology (KIT). The blocks and beams made from the innovative bonding agent are being tested as part of load-bearing constructions. The mechanical behavior of the material under loads is evaluated with regard to its strength, crack formation, and durability. It can be said at this point that the carbon in the material remains stable under the applied loads.
Importance of the matter for the construction industry
This new concrete does not only have to be strong initially but also have durability. The material should resist many years of pressure, climatic variation, and structural strain. This is why engineers are evaluating whether the new concrete can perform like regular concrete regarding compressive strength, cracking resistance, protecting steel reinforcement, and general stability. In any case that carbon sequestration is effective, the material will not be adopted if it fails to satisfy construction safety standards.
The need for alternative solutions
For many years, one of the ways in which emissions from cement had been minimized was through the use of industrial waste products, including fly ash and slag, produced by the burning of coal and steel production respectively. These waste products have been used to replace a portion of the cement that has been added to concrete. However, this solution is no longer working since there are fewer coal-fired power plants as well as changes in steel production process.
The development of concrete mixes is an intricate process that takes much time. In order to accelerate the process, scientists make use of machine learning and simulation. Such technology helps select appropriate combinations of materials prior to any practical testing. Moreover, computer programs enable predicting the future behavior of concrete in terms of curing, cracking, and load transfer.
Challenges for mass implementation
Although this technology has yielded some positive results, numerous challenges remain that could prove to be stumbling blocks to its widespread adoption. First, its longevity needs to be established after a prolonged period. Second, it must be compatible with steel reinforcements, which are commonly used in construction. Third, its manufacturing costs must be equivalent to those of normal cement, while adjustments to building regulations must be made. Finally, its large-scale production in industry poses another challenge.
However, if all these problems were to be solved, the effect would definitely be impressive. First, the buildings would act as a carbon sink because they can store the carbon dioxide in their construction. The construction sector, which is one of the greatest emitters, will become a sink for carbon dioxide instead. Another great advantage is that the emissions from industry can be recycled in construction materials.
Way Forward
The development of this new kind of concrete is still at an experimental stage, but it looks like this could be the way to go for the construction industry in the future. Through transforming carbon dioxide into a mineral form and integrating this mineral into structures, scientists seek to build infrastructure that would not only sustain the current state of things but also decrease the amount of carbon in the atmosphere.
